DESOI PN1025 one-component injection pump for polyurethane & epoxy

DESOI PN1025 is a German-made, one-component injection pump for polyurethane and epoxy resins with infinitely variable 5–220 bar working pressure and up to 4.5 L/min delivery — built for fast, reliable injection on site.

DESOI PN1025 is a mobile, one-component injection pump designed for dispensing polyurethane and epoxy injection resins, as well as aqueous solutions. It’s engineered for consistent pressure control and dependable flow, helping contractors complete injection work efficiently and safely.

• Working pressure: 5–220 bar (infinitely variable)

• Max delivery: 4.5 L/min

• Air consumption: 500 L/min

• Max air pressure: 0.8 bar

• Transmission ratio: 1:27

• Weight: ~14 kg

• Dimensions (H × W × L): 690 × 450 × 350 mm

• Mobile frame with wheels

• 5 m high-pressure material hose, Ø 6 mm

• High-pressure ball valve with mouthpiece

• 6 L material container with lid

• Instruction manual

• MC 2300NV — a flexible polyurethane resin ideal for sealing and waterproofing in water- or liquid-holding structures such as tanks, pits and reservoirs.

• MC 1264M — a low-viscosity, force-transmitting epoxy resin for structural crack injection and concrete repair where rigid, high-strength bonding is required.

PN1025 sits at the centre of a one-component injection workflow: the pump delivers the resin through appropriate packers and hoses to fill cracks, joints and voids. With compatible DESOI accessories and technical support, you can configure an end-to-end solution tailored to your project.

For best results and a fit-for-purpose outcome, follow the relevant Technical Data Sheets (TDS) and Safety Data Sheets (SDS) for the resin selected. Observe standard practices for surface preparation, cleaning, application and curing. Always use appropriate PPE and confirm site-specific requirements before starting.
